AR series - Geophysical maps

Size: 1254x868, 8 bits (256 colors) - ideal for 1280x desktop
These maps are NON mercator projection, so there is always a small error specially at AR1 level.

Note1: If you use UI-16 or older versions of UI-32, you HAVE to convert PNG maps to GIF. You can do it with practically every image processing program like PSP or PhotoShop or even ACDSee and IrfanView.

Note2: I design maps for 1280x960 desktop so the entire map fits on my UI-View in full screen mode without scrolling bars (i hate map shift). If you use lower resolution like 1024x768 etc., it may be better to RESIZE the maps to fit in your window. Resizing does NOT affect correct calibration, so feel free to experiment...

Note3: You may also experiment editing the maps with latest details and add/remove just about anything! Don't change physical details... Also 256 color maps have a "palette" feature. If you don't like the color of the sea, don't edit the map! Find and change the reference color in the palette instead. Then save the palette (with a filename like myAR.pal), and apply it to all AR1 maps for example. Now all your AR1 maps have a new sea color!

AR1 = 87km Range Scale in UI-view (relief)

AR1Athens.png 199.42 KB	AR1CMacedonia.png 244.71 KB	AR1Cyclades.png 59.10 KB	AR1EAegean.png 85.27 KB
AR1ECrete.png 64.63 KB	AR1Ipiros.png 273.72 KB	AR1NAegean.png 84.54 KB">	AR1Olympos.png 222.19 KB
AR1Patra.png 252.19 KB>	AR1Peloponnese.png 134.42 KB	AR1Rhodes.png 77.81 KB	AR1Sterea.png 242.48 KB
AR1Thace.png 264.48 KB	AR1WCrete.png 79.59 KB	AR1WMacedonia.png 313.83 KB
